Tech Specs sonnenBatterie eco
The sonnenBatterie eco is an energy storage solution for your home that uses intelligent software to manage energy throughout the day saving you money, providing backup power and enabling you to use your solar power at night.
| eco 4 | eco 6 | eco 8 | eco 10 | eco 12 | eco 14 | eco 16 | |
|---|---|---|---|---|---|---|---|
| Usable capacity (100% DOD) | 4 kWh | 6 kWh | 8 kWh | 10 kWh | 12 kWh | 14 kWh | 16 kWh |
| 1RPLQDO power rating (at 25 deg C) | 3 kW | 4 kW | 4 kW | 7 kW | 8 kW | 8 kW | 8 kW |
| Weight (approximate) | 377 lbs | 437 lbs | 496 lbs | 622 lbs | 683 lbs | 741 lbs | 800 lbs |
| Dimensions W/H/D (approximate) | 26/55/14 | 26/75/14 | |||||
| 11.5 A | 15 A | 15 A | 28 A | 30 A | 30 A | 30 A | |
|---|---|---|---|---|---|---|---|
| Max Power | 100 ms 8.5 KVA 5 s 6 KVA 30 m 4.5 KVA | 100ms 17 KVA 5 s 12 KVA 30 m 9 KVA | |||||
| Max AC current (charge/discharge) | 1 ms 50 A 100 ms 35.35 A 5 s 25 A 30 m 18.75 A | 1 ms 100 A 100 ms 70.7 A 5 s 50 A 30 m 37.5 A | |||||
General Specifications
Grid integration
AC coupled
Applications
On-grid: self-consumption
Off-grid: backup
Off-grid: backup
Transfer switch
Automatic, integrated
Backup capacity
2 kilowatt-hours per battery module, up to 16
Listed and recognized components
Certified to UL1741 (inverter) and UL 1973 (batteries)
Warranty*
Inverter, 10 years; battery modules,
10 years or 10,000 cycles; cabinet and components, 1 year
10 years or 10,000 cycles; cabinet and components, 1 year
Inverter effciency
92.5% CEC weighted, 95.0% peak
Roundtrip Ef%
(Grid<>Battery)
(Grid<>Battery)
>= 86%
Ventilation
Forced Air
Comm. ports
Serial, Ethernet
Communication protocols
Modbus, Z-Wave, CANbus (ready),
WiFi (ready)
WiFi (ready)
Communication and
control standards
control standards
Open ADR 2.0, SunSpec Alliance
EMC / EMI protection
FCC Part 15B
